ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery

ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery
ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery

Large Image :  ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery

Product Details:
Place of Origin: SHENZHEN,CHINA
Brand Name: PF
Certification: SGS
Model Number: 1183
Payment & Shipping Terms:
Minimum Order Quantity: 500 pcs
Packaging Details: plastic bag packing in a certain quantity; carton package with shrink film wrapping outside
Delivery Time: 3~5 work days
Payment Terms: T/T
Supply Ability: 500000 per day

ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery

Description
Adhesive: Silicone Adhesive Type: Polyimide Tape
Die-cutting: Sheets Or Other Any Shapes Feature: Waterproof Removable MASKING
Thickness: 0.06mm,0.08mm Etc Name: Kaptone Polyimide Tape
Sample Order: Welcome Width: Customized Size
Usage: Heat-Resistant Color: Amber
High Light:

Die Cut Polyimide Masking Tape

,

Insulation Polyimide Masking Tape

,

ESD Polyimide Tape

Double Coating With Silicone Adhesive Die Cut Kapton Tape Pi Polyimide Film Electrical Tape



What is polyimide tape and main feature?

Polyimide tape is polyimide film as the baking and coated with imported pressure-sensitive silicone adhesive.It can withstand high temperature up to 260 ° C in half an hour,Electrical insulation, radiation resistance, solubility resistance, heat resistance, etc



Can I Have Details of this Product?

Yes, Common Data are in the Following Table.

Backing Polyimide film
Coefficient of the tape Silicone
Color amber/black
Film thickness(mm) 0.025 0.025 0.05 0.05 0.075 0.125 0.125 0.15
Total thickness(mm) 0.05 0.06 0.08 0.1 0.12 0.15 0.18 0.2
Fluorine release liner thickness(mm) 0.05 0.05 0.075 0.075 0.075 0.075 0.075 0.075
Length(m) 33m/max 750m
Tensile Strength(KG/25mm) 20 14 45 45 45 45 45 45
Elongation % 60 65 65 65 65 65 65 65
Breakdown strength ≥150N/25mm
Withstand VoltageKV 6 6 10 10 10 10 10 15
Adhesion (N/25mm ) 5 6 6.5 6.5 5.5 5.5 6 6
Temperature Resistance℃ 280℃ 30mins



ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery 0ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery 1ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery 2




P.S:
1.Please help provide what size of double sided adhesive tape you need.Thanks!
2.Please help provide what thickness you need.Thanks!
3.Pls help provide what the double sided adhesive tape used for.Thanks!

PF will provide professional and kind recommendation if no idea to use suitable Tape material.
Best Material Option! Applicable Material With Cost Down Option!



Die Cutting Method
♦ Rotary Die Cutting
♦ Flatbed Die Cutting
♦ Steel Rule Die Cutting
♦ Laser Die Cutting
♦ Punching

Die Cutting Material
♦ Brand 3M/Nitto/Poron Tape
♦ Single/Double Coated Tapes
♦Foam/Aluminum/Copper Foil
♦Rubber/Silicone/Films/Mica
♦Paper Material/Screens



Why PUFENG?
A:The professional tape manufacturer including PE/Acrylic/Rubber Foam Tape/Polyimide/Tissue Tape
B:3M/Poron/Tesa agency in China
C:Own die cutting machines,provide custom service according to CAD/PDF drawing or requirement.
D:Rich experience in double tape and die cutting,professional suggestion for your proejcts.
E:Various die cut tape material options.

SERVICE:
Precision Tape Slitting:
Specializes in providing custom and narrow width precision tape slitting rolls


Die Cutting Services:
Die cutting a variety of tapes to your exact specifications.
Customization is our specialty.

Tape Lamination Services:
Laminating foams, films or other substrates with adhesives to make custom constructions.

About us:

ESD Silicon Die Cut Insulation Polyimide Masking Tape For Battery 3


Packaging & Delivery
1.As Required From Customer
2.Single---Several Hundred Pieces Sealed In Transparent OPP Bag
2.Sheet---Several Sheets Sealed With PE Film Or In Opp Bag,Several Bags Packed In Export Papar Carton.
3.Roll---Several Roll Is Packed In Export Paper Carton,Each Roll Is Separated By Release Paper Or Hardboard.
