Rogers Bisco HT-870 Soft Cellular Silicone foam, Density is 240kg/m³

Name: Rogers Bisco HT-870 Soft Cellular Silicone foam, Density is 240kg/m³
Brand: SZ PUFENG PACKING MATERIAL LIMITED
SKU: BISCO HT-870
Price: 25.00 USD
Availability: InStock

Brand Name:	Rogers
Model Number:	BISCO HT-870
MOQ:	1roll
Price:	USD1~USD50
Delivery Time:	3~5working days normally
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand:

ROGERS

Series:

BISCO

Model:

HT-870

Color:

Red/Black

Materials:

Silicone

Thickness:

1.59mm ~ 12.7mm

Density:

240 Kg/m³

Feature:

Cushioning And Vibration Isolation

Specification:

Customizable

Packaging Details:

packing in cartons

Supply Ability:

10000roll/week

Highlight:

Rogers Bisco HT-870 silicone foam

cellular urethane foam with 240kg/m³ density

soft cellular silicone foam sheet

Product Description

Rogers Bisco HT-870 Soft Cellular Silicone Foam

Density: 240kg/m³

Product Description

Rogers BISCO HT-870 Soft Cellular Silicone is a firmer, denser version of our BF-1000 Silicone and offers the ability to seal and cushion within a wide range of applications.

Product Features

Low gas release performance
Good sealing property
Ultraviolet resistance
Inflaming retarding
Mechanical properties: High compressibility enables adaptation to different gap widths. Slow rebound performance reduces the risk of gasket failure. Low stress relaxation lowers maintenance costs

Product Applications

Application fields	Specific use	Core values
Outdoor electronic equipment	Lighting enclosure, HVAC device, electronic cabinet sealing	Dust-proof, water-proof, and light-proof
Automobiles and Electrical	Shock Absorbers, Gaskets, Safety Airbag Components	Absorb shock and reduce vibration noise
Batteries and energy equipment	Battery pack fireproof and waterproof sealing strips, vibration isolation pads	Flame retardant and heat insulation, enhanced air tightness

Product Parameters

Brand	Rogers
Series	BISCO
Model	HT-870
Color	Red / Black
Adhesive	With or without
Material	Cellular Silicone
Total Thickness	1.59mm ~ 12.7mm (0.063 ~ 0.500 inches)
Processing	Customization based on the provided CAD and PDF format drawings
Temperature range	-55 ~ 200℃ (-67 ~ 392℉)

Performance Parameters

PROPERTY	TEST METHOD	TYPICAL VALUE
Density, kg/m³ (lb./ft³)	Internal	240 (15)
Compression Force Deflection, kPa (psi)	ASTM D1056	26 (3.8)
Compression Set, %	ASTM D1056 100°C (212°F) / 22 hrs / 50%	1.6
Water Absorption, %	Internal 2" below water surface / 24 hrs / change in weight	0.5
Thermal Conductivity, W/m °K	ASTM D518	0.06
Low Temperature Flex	ASTM D1056 -55°C (-67°F) / 5 hrs	Pass
Low Temperature Brittleness	ASTM D746 -55°C (-67°F) / 3 min	Pass

Product Display

Packing & Transport

Company Profile

SHENZHEN PUFENG PACKING MATERIAL CO.,LTD (PUFENG) is an international machining manufacturer, who is devoting to the precision die-cutting machining field, designing adhesive products, insulation products, sourcing the best solutions and improving the quality and performance of products for customer.

Our export products are diverse, including adhesive products, insulating products, foam and sponge, as well as other industrial raw materials. They are composed of multiple brands: 3M, Nitto, Sony, TESA, Teraoka, Bergquist, Rogers, INOAC, and our domestic brand, etc.

Welcome to come for consultation! We will do our best to solve all your connection problems and provide you with professional solutions and applicable products.

Our Services

Your enquiries about our products will be answered within 12 hours.
OEM or ODM projects are very welcome.
We can die cut or design products according to your requirements (shock-proof, shading, etc.).
Provide perfect after-sales service, if you have questions, please contact us.
Pack according to your requirement and deliver on time.

Common Questions

How to order from Pufeng?
Just send us an email or call us.

Do you provide free samples for testing?
Yes, we provide samples free of charge.

How to deliver the goods?
We will advise you on the appropriate mode of transport, sea, air or express. Of course, if you have your own repeater, that's no problem.

Can we trust the quality of Pufeng products?
Of course, don't worry. Our quality will definitely match the samples we send. If not, we will be responsible.

What payment does Pufeng accept?
For small quantities, we require 100% TT payment in advance; Other conditions, negotiable.

What is the lead time of each order?
If the tape you ordered is in stock, we can deliver it within 1~3 days. If die cutting is required, delivery time shall be determined by quantity.
