TESA 60233 Black Single Side Matte PET Base Aluminum Foil Conductive Cloth Tape

Name: TESA 60233 Black Single Side Matte PET Base Aluminum Foil Conductive Cloth Tape
Brand: SZ PUFENG PACKING MATERIAL LIMITED
SKU: 60233
Price: 25.00 USD
Availability: InStock

Brand Name:	TESA
Model Number:	60233
MOQ:	1roll
Price:	USD1~USD50
Delivery Time:	3~5working days normally
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand:

TESA

Model:

60233

Base Material:

PET/ Aluminum Foil/conductive Non-woven Fabric

Color:

Black

Backing:

PE Coated Paper

Adhesive:

Conductive Acrylic Acid

Total Thickness:

60 μm

Temperature Range:

Long-term100℃ , Short-term200℃

Characteristic:

Strong Viscosity And Wear Resistance

Specification:

500mm × 50m (Customizable)

Packaging Details:

packing in cartons

Supply Ability:

10000roll/week

Highlight:

aluminum foil conductive cloth tape

TESA super adhesive single sided tape

60233 super adhesive single sided tape

Product Description

TESA 60233 Black single side matte PET base aluminum foil conductive cloth tape

Product description :

TESA 60233 is a single side matte black conductive tape. It is made of matte black PET substrate, aluminum foil and conductive non-woven fabric laminated.The conductive adhesive is coated on one side of the substrate non-woven fabric.

Product features /Application :

Thickness :60 μm

Excellent XY direction conductivity, ground performance

The top PET film provides insulation

High adhesion in harsh environmental conditions to prevent edge warping

Minimal bending is easy to handle and past

Matte black surface to prevent handprint residue, solvent resistance

Mainly used in LCD and metal BLU chassis grounding

PRODUCT PARAMETERS

Brand	TESA	Model	60233
Base material	PET	Color	Black
Backing	PE coated paper	Adhesive	Acrylic acid
Total thickness (μm)	60 μm	Specification	500mm × 50m (Customizable)

PROPERTIES / PERFORMANCE VALUES

23°C static shear resistance

Good

Long-term high temperature resistance

(℃)

100 ℃

40°C static shear resistance

Good

Short-term high temperature resistance

(℃)

200 ℃

Surface resistance x-y direction

(Ohm / square)

0.2

Ohm / square

PEEL STRENGTH PARAMETER VALUE

Material

Initial peeling strength
( N/cm )

Peel strength after 14 days
( N/cm )

Steel

4.4

5.0

PRODUCT DISPLAY

PACKING OF TRANSPORT

TESA 60233 Black Single Side Matte PET Base Aluminum Foil Conductive Cloth Tape 2

COMPANY PROFILE

SHENZHEN PUFENG PACKING MATERIAL CO.,LTD (PUFENG) is an international machining manufacturer, who is devoting to the precision die-cutting machining field, designing adhesive products, insulation products, sourcing the best solutions and improving the quality and performance of products for customer.
The operation principle of PUFENG is "Running based on the market and sincerity,client and high quality come first." In order to provide a complete set of on-step products and service to customer, PUFENG has formed a strong technical team for worldwide customers to develop precision products. PUFENG’s quality principle is “Serve customers precisely on every tiny point of the demand from customer.” We hope to build up business relationships with you on the basis of equality and mutual benefit.

OUR SERVICES

1.Your enquiries about our products will be answered within 12 hours.

2.OEM or ODM projects are very welcome.

3.We can die cut or design products according to your requirements.shock-proof, shading, etc.

4.Provide perfect after-sales service, if you have questions, please contact us.

5.Pack according to your requirement and deliver on time.

COMMON PROBLEM

1.)How to order from Pufeng?
Just send us an email or call us.

2.)Do you provide free samples for testing?
Yes, we provide samples free of charge.

3.)How to deliver the goods?
We will advise you on the appropriate mode of transport, sea, air or express. Of course, if you have your own repeater, that's no problem.

4.)Can we trust the quality of Pufeng products?
Of course, don't worry. Our quality will definitely match the samples we send. If not, we will be responsible.

5.)What payment does Buffon accept?
For small quantities, we require 100% TT payment in advance; Other conditions, negotiable.

6.)What is the lead time of each order?
If the tape you ordered is in stock, we can deliver it within 1~3 days.
If die cutting is required, delivery time shall be determined by quantity.
