| Brand Name: | 3M |
| Model Number: | 5952 |
| MOQ: | 1000 pieces |
| Price: | USD 0.1~0.5 / piece |
| Delivery Time: | 3~10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
adhesive tape double sided 3M 5952 High Performance Use Black 3M VHB Tape Waterproof Acrylic Foam
PRODUCT DESCRIPTION
Fast and easy-to-use permanent bonding method provides high strength and long-term durability.
Virtually invisible fastening keeps surfaces smooth.
Can replace mechanical fasteners (rivets, welds, screws) or liquid adhesives.
General purpose adhesive and firm acrylic foam core.
Eliminate drilling, grinding, refinishing, screwing, welding and associated clean-up.
Creates a permanent seal against water, moisture and more.
Pressure sensitive adhesive bonds on contact to provide immediate handling strength.
Allows the use of thinner, lighter weight and dissimilar materials.
3M™ VHB™ Tape 5952 is a very conformable, double-sided, pressure-sensitive, closed-cell acrylic foam tape.
It bonds high, medium and medium/low surface energy substrates. Provides handling convenience, cushioning, damping, and impact resistance.modified acrylic adhesive on both sides of a very conformable adhesive foam core, providing adhesion the broadest range of substrates, including most powder coated paints.
3M Double Side Tape 5952, Jumbo roll size is 610mm(width) x 33m(length), we can die cut any size and any shape according to customer's request or drawing. We have mould of following sizes, can die cut them at any time quickly:
FEATURES
* Waterproof, sound and shake proof
* UV resistance
* Excellent adhesion to metal, plastic, wood, leather, paper which is hard to stick material
APPLICATION
* Dustproof and airproof of glass curtain wall assembly
* Building operations such as heat insulation, connection, bundling, amendment, sealing
* Electronic, digital products assembly and processing
* Automotive industry: nameplate, decoration bars, marks, a ideal substitution for 3M VHB tape
CONSTRUCTION
| Red PE Film |
| Pressure Sensitive Adhesive |
| Acrylic Foam |
| Pressure Sensitive Adhesive |
PHYSICAL PROPERTIES
| Item | Unit | Value | Test Method |
| Carrier | Acrylic Foam | ||
| Adhesive | Acrylic | ||
| Color | Clear | ||
| Thickness | mm | 1.00±50μm | ASTM-1000 |
| Standard Roll Width | mm | 800 | |
| Standard Roll Length | m | 33 | |
| Tensile Strength | Gf/cm² | ≥7,000 |
(T-Block) To Aluminum |
| Peel Adhesion | gf/25mm | ≥4,000 |
To Stainless Steel Room Temperature 180°Peel |
|
Holding Power
|
Hr | >24 |
To Stainless Steel 80℃ Temperature 1000g Static Load |
SHELF LIFE
Product shelf life is 2 years from date of manufacture when stored at room temperature conditions (72°F [22°C] and 50% RH) in the products original packaging.
AVAILABLE SIZES
Width: Maximum width 31.5 inches (800 mm). (Can be Customized)
Length: 33m (Can be customized).
Custom Sizes: If you need customized sizes or die cut parts please feel free to contact sales representative.
Our Services
1. Your inquiry related to our product will be replied within 12 hours.
2. OEM or ODM projects are highly welcome.
3. We can die cut or design the products according to your requirements.
4. Perfect after-sale service offered,please contact us if you got question.
5. Packing as your request and promptly delivery
FAQ
1) How to order from PUFENG?
Just send us email or call us.
2) Do you offer the free sample for testing?
Yes, we offer thee samples for free.
3) How to ship the order?
We will suggest you the appropriate way of shipment, by sea, by air or by courier. Of course if you will have your own forwarder, that is no problem.
4) Can we trust the quality of product from PUFENG?
Sure, do not worry about that. Our quality wills absolutely compliance to the sample we send. If not, we will take charge of that.
5) What payment PUFENG accepts?
For the small quantity, we request 100% advanced TT payment; other conditions, negotiable.
6) How about the lead time of per order?
If the tape you order have stock, we can ship out within 1~3 days.
If die-cuts requested, the lead time shall be according to the quantity.
|
