0.25mm Thermal Conductive Pad thermal conductive silicone pad
Place of Origin Guangdong,China Mainland
Brand Name PF
Certification ROHS
Model Number 00
Minimum Order Quantity 1 piece
Price USD 0.5 per piece
Packaging Details Standard package for export
Delivery Time 3~10 work days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 1000000 pieces per day
Product Details
Material Silicone Type Insulation
Temperature Resistance -60C~220C Thickness 0.25mm~12mm
Thermal Impedance 0.25 ℃-in2/W Application High Voltage
High Light

0.25mm Thermal Conductive Pad


12mm Thermal Conductive Pad


RoHS high conductivity thermal pad

Product Description

Thermal conductive silicone pad Insulation electric thermally conductive silicone thermal pad LED Thermal Pad




LED Thermal Pad


LED thermal pad is a high performance thermal conductive gap filling material, mainly used for thermal interface between electronic components and heat sink or product outer covering.



*  Excellent thermal conductivity

*  Self-adhesive, natural sticky, no extra surface added adhesives

*  Soft and flexible

*  Wide working temperature range

*  Various thicknesses for choice

*  Stable and Economy



*  Communication equipment

*  LED lighting

*  Switch power supply

*  Backlight module

*  Medical equipment

*  Mobile equipment

*  Video equipment

*  Household equipment





Property Unit Test Value Test Method
Specific Gravity g/cm3 2.3 ASTM D792
Harness Shore A 40°-60° ASTM D2240
Thermal Conductivity W/m-k 1.5 ASTM D5470
Fire Retardant Rating - V-0 UL-94
Specific Inductive Capacity (SIC) Kgf/cm2 5.5 ASTM D412
Dielectric Breakdown Kgf/cm 0.5-7.4 ASTM D1458
Voltage Withstand Kv/mm ≥5.5 -
Thermal Impedance ℃-in2/W 0.25 ASTM D5470
Temperature Resistance -60℃~220℃ EN344
Tension Changes % +50 ASTM D573
Extension Changes % -25 ASTM D573
Volume Changes %(0.3/m) +2% 24 hr/25℃
Thickness mm 0.25-12mm ASTM D347




Note: The above technical information and data should be considered representative or typical only and should not be used for specification purposes.



Product shelf life is 2 years from date of manufacture when stored at room temperature conditions (72°F [22°C] and 50% RH) in the products original packaging.



Available Sizes: 200mm*400mm, 300mm*300mm etc. (Can be Customized)

Custom Sizes: If you need customized sizes or die cut parts please feel free to contact sales representative.

0.25mm Thermal Conductive Pad thermal conductive silicone pad0.25mm Thermal Conductive Pad thermal conductive silicone pad0.25mm Thermal Conductive Pad thermal conductive silicone pad0.25mm Thermal Conductive Pad thermal conductive silicone pad


Our Services

1. Your inquiry related to our product will be replied within 12 hours.


2. OEM or ODM projects are highly welcome.


3. We can die cut or design the products according to your requirements.


4. Perfect after-sale service offered,please contact us if you got question.


5. Packing as your request and promptly delivery






1) How to order from PUFENG?

Just send us email or call us.


2) Do you offer the free sample for testing?

Yes, we offer thee samples for free.


3) How to ship the order?

We will suggest you the appropriate way of shipment, by sea, by air or by courier. Of course if you will have your own forwarder, that is no problem.


4) Can we trust the quality of product from PUFENG?

Sure, do not worry about that. Our quality wills absolutely compliance to the sample we send. If not, we will take charge of that.


5) What payment PUFENG accepts?

For the small quantity, we request 100% advanced TT payment; other conditions, negotiable.


6) How about the lead time of per order?

If the tape you order have stock, we can ship out within 1~3 days.

If die-cuts requested, the lead time shall be according to the quantity.
