|Product Name:||PTFE Cloth Film Tape||Material:||PTFE,PTFE Coated Fiberglass With Silicone Adhesive|
|Usage:||Electronic Industry Ect||Color:||White,black,brown|
|Feature:||Heat-Resistant,Sealing Performance,Heat Resistance,Waterproof,Antistatic||Size:||Customized Size|
RoHS PTFE Glass Cloth Tape,
7KV PTFE Glass Cloth Tape,
0.13mm high temperature insulation tape
High Quality Best Price ptfe Tape High Temperture Tape 0.13mm
1. UL510 certification
2. Superior mold release and sliding properties
3. High voltage insulation up to 7KV
4. Good holding property at elevated temperatures and dimentsional stability
5. The non- adhesive side exhibits, excellent characteristics of PTFE
6. Electrical properties, heat resistance,. weather ability,chemical resistance, water resistance and non- adhesion .
1. For heat- resistant masking
2. For electronic insulation, high voltage cable wrapping
3. For heat sealing of food and medicine including themoplastic, compositing, thermoplastic sealing , electonic and elctrical industry
4. For heat resistant electrical insulation
5. Chute and hopper linings
6. Surface coating of sizing rolls for dying and resin treatement
7. Masking protection for plasma spray
8. Other applications which require heat resistant, wearing - resisting, anti- corrosion and anti- adhesive
|Adhesive strength at 25 centigarde||8.2N/19mm|
|Adhesive strength at 100 centigarde||3.6N/19mm|
|Adhesive strength at 150 centigrade||2.5N/19mm|
|Unwinding force||5.7N/ 19mm|
|Temperature range||-60-280 centigrade|
PTFE silicone Adhesive glass-cloth tape High Temperature Tape is consisting of PTFE(polytetrafluoroethylene) film and silicone adhesive layer. Have advantages of excellent heat resistance,insulation, sliding, chemical resistance.Nitto Denko 903ul PTFE Adhesive tape High Temperature Tape is not only as a heat resistant tape but also to be used for various applications.
* Smooth surface, easy clean
* Non stick, reusable
* Chemical resistance
* Insulating properties
Any special requirements please contact us , we can do any size of the goods according to the requirements of customers.
1. Your inquiry related to our product will be replied within 12 hours.
2. OEM or ODM projects are highly welcome.
3. We can die cut or design the products according to your requirements.
4. Perfect after-sale service offered,please contact us if you got question.
5. Packing as your request and promptly delivery
1) How to order from PUFENG?
Just send us email or call us.
2) Do you offer the free sample for testing?
Yes, we offer thee samples for free.
3) How to ship the order?
We will suggest you the appropriate way of shipment, by sea, by air or by courier. Of course if you will have your own forwarder, that is no problem.
4) Can we trust the quality of product from PUFENG?
Sure, do not worry about that. Our quality wills absolutely compliance to the sample we send. If not, we will take charge of that.
5) What payment PUFENG accepts?
For the small quantity, we request 100% advanced TT payment; other conditions, negotiable.
6) How about the lead time of per order?
If the tape you order have stock, we can ship out within 1~3 days.
If die-cuts requested, the lead time shall be according to the quantity.
