High Tensile Strength 20um-100um Copper Foil Tape , RoHS Aluminum Foil Tape Heat Resistance
Place of Origin Guangdong,( Mainland)
Brand Name PF
Certification ROHS
Model Number COPPER FOIL
Minimum Order Quantity 1 Kilogram/Kilograms
Price USD 1 per Kilogram/Kilograms
Packaging Details Standard package for export
Delivery Time 3~7 work days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 100000 Kilogram/Kilograms per Month copper tape
Product Details
Product Name Aluminum Foil Tape Material Aluminium Foil
Adhesive Acrylic Feature Heat-Resistant,Antistatic
Color Silver Adhesive Side Single Sided
High Light

20um Copper Foil Tape


100um Copper Foil Tape


RoHS aluminum foil tape heat resistance

Product Description

Adhesive aluminium foil tape conductive adhesive copper /aluminum tape




1)  High tensile strength aluminum foil made from special high quality aluminum foil, coated with aggressive solvent-based acrylic adhensive/acrylic adhensive/ synthetic rubber , which provide strong stickiness, good peel strength, high tensile strength and great ageing resistance.

2)  Base Material: aluminum foil tape. Thickness can be customized.

3)  Adhesive: acrylic press-sensitive adhesive

4)  Core: Φ762mm

5)  Widely be used in refrigerators and freezers, etc.




Material: Aluminum Foil
Adhesive: Acrylic
Adhesive Side: Single Sided
Place of Origin: China (Mainland)
Temp. Resistance -20-+120°C
Peel strength ≥10N/25mm
Initial adhesion ≤10cm/Φ11mm steel-ball
Width: 25-1000mm
Length: Ascustomer's require 10/20/30/50m etc
Thickness: 20u-100u
Color: Silver
Print: No printing
Main Markets: North-America/Eastern Europe/Southeast Asia/Mid East/Eastern Asia/Western Europe/South America/Africa





Household electrical appliances

HVAC sectors


Package etc


  Industry Self Adhesive Aluminum Foil Tape
  The tape is used for heat-resistanting in pipelines.

Item Name Self Adhesive Aluminum Foil Tape
Material Aluminum foil
Thickness 30, 40, 50 micron Aluminum foil

50mm x 50m, 75mm x 50m, 100mm x 50m, 48mm x 50m.

We also offer special sizes for customer.

Adhesive Solvent acrylic or water acrylic
Usage Suitable in electronic and refrigeration fields due to its excellent thermal- and electrical conductivity.


Aluminum Foil Tape is a 30u nominal dead soft aluminum foil with cold weather flame-retardant acrylic adhesive and protected by easy release liner.



Excellent Peel Adhesion

Good Initial Tack & Permanent Bonding

UL 723 Fire Rating Approval

Outstanding Low Temperature & Aging Resistance


Super performance, UL 723 FR grade 30u foil tape. Ideal for sealing joints / seams against moisture and vapor on foil jacketing insulation. Suitable for many other permanent sealing, holding, splicing or masking applications requiring the protection offered by a foil backing.



Technical Data Sheet:

Property Unit Value Test Method
Backing Thickness Micron 30 PSTC-33 / ASTM D3652
Peel Adhesion N/25mm 15 PSTC-1 / ASTM D3330
Tack Rolling Ball cm 5 PSTC-6 / ASTM D3121
Tensile Strength N/25mm 37.5 PSTC-31 / ASTM D3759
Holding Power min/25*25mm2 1kg weight 10000 PSTC-7 /ASTM D3654
Elongation % 3.0 PSTC-31 / ASTM D3759
Fire Rating (25 / 50 & Class O) Passed UL 723 & BS476 Pt 6 & 7
Service Temperature -40 +120 ----------
Applying Temperature -5 +40 ----------

Cut Roll: 48mm, 50mm (2"), 60mm, 63mm (2.5"), 72mm, 75mm (3"), 96mm, 100mm (4").

  Jumbo Roll: 1200mm x 1350M, 1200mm x 1200M.

High Tensile Strength 20um-100um Copper Foil Tape , RoHS Aluminum Foil Tape Heat Resistance


Our Services

1. Your inquiry related to our product will be replied within 12 hours.

2. OEM or ODM projects are highly welcome.

3. We can die cut or design the products according to your requirements.

4. Perfect after-sale service offered,please contact us if you got question.

5. Packing as your request and promptly delivery






1) How to order from PUFENG?

Just send us email or call us.


2) Do you offer the free sample for testing?

Yes, we offer thee samples for free.


3) How to ship the order?

We will suggest you the appropriate way of shipment, by sea, by air or by courier. Of course if you will have your own forwarder, that is no problem.


4) Can we trust the quality of product from PUFENG?

Sure, do not worry about that. Our quality wills absolutely compliance to the sample we send. If not, we will take charge of that.


5) What payment PUFENG accepts?

For the small quantity, we request 100% advanced TT payment; other conditions, negotiable.


6) How about the lead time of per order?

If the tape you order have stock, we can ship out within 1~3 days.

If die-cuts requested, the lead time shall be according to the quantity.
